Name: IP54 Protected Anti-Tamper Smart Prepaid 4G/GSM/GPRS Electricity Meter with Vending Software STS
Brand: Hunan Stron Smart Co., Ltd
SKU: STE18/STE38
Price: 463.90 USD
Availability: InStock

Home > Products > Smart Prepaid Electricity Meter >

IP54 Protected Anti-Tamper Smart Prepaid 4G/GSM/GPRS Electricity Meter with Vending Software STS

IP54 Protection Smart Prepaid Electricity Meter

Anti-Tamper Prepaid Energy Meter

Vending Software STS Standard Electricity Meter

Place of Origin:

China

Brand Name:

stron

Certification:

STS

Model Number:

STE18/STE38

Request A Quote

Product Details

Product Name:

Prepaid Smart Single Phase Keypad GPRS Energy Meter

Display:

LCD

Output Voltage:

230v

Working Voltage Range:

23%~120%Un

Minimum Operating Voltage:

50V

Maximum Current (Imax):

80A

Input Way:

Keypad

Payment Method:

Through Token

Storage Temperature:

-40℃-85℃

Nominal Frequency:

50-60Hz

Anti Tamper:

Yes

Energy Usage History:

Available

Communication:

LORA-RF Supported

Alerts And Notifications:

Yes

Accuracy Class:

Class 1.0

Battery Life:

8 Years

Rated Voltage:

230V

Standard:

STS Standard

Frequency:

50-60HZ

Warranty:

2 Years

OEM/ODM:

Support

Certificate:

ISO9001; ISO14001; STS Standard

Vending Software:

Supported

Recharge Token Length:

20 Digits

Protection Class:

IP54

Current Range:

5A/80A

Starting Current:

20mA

Energy Constant:

1000imp/kWh

Measurement Accuracy:

Class 1.0

Mobile Payment Support:

M-PESA, Alipay, MTN, Airtel, Etc.

Overdraft Collection:

Daily/monthly Optional

Data Storage Duration:

10 Years

Anti-Tampering:

Both With Magnetic Field/cover-opening Detection; STE18-B Cuts Relay, STE38-G Shuts Valve When Triggered

Recharge Method:

(1. Stronpay Software; 2. 3rd-party/mobile Payment)plus 3. AMI System Remote Recharge)

Highlight:

IP54 Protection Smart Prepaid Electricity Meter

Anti-Tamper Prepaid Energy Meter

Vending Software STS Standard Electricity Meter

Payment & Shipping Terms

Minimum Order Quantity

Price

negotiated

Packaging Details

0.68*0.41*0.155m

Delivery Time

Payment Terms

T/T

Supply Ability

9999999 unit

Prepayment Smart Prepaid Electricity Meter Featuring Class 1 Accuracy and Prepaid Token Type Mode Suitable for Commercial

Get Best Price

STS Prepaid Electricity Meter High Accuracy Energy Meter with Remote Monitoring System

Get Best Price

Video

STS Prepaid KWH Meter 1 Phase Digital Electric Meter for Utility Companies Operates normally at an ultra-low voltage of 50V

Get Best Price

Multi-Tariff Dual Source Electricity Meter STS Compliant for Industrial/Commercial/Residential Use

Get Best Price

Contact Now

Product Description

IP54 STS Smart Prepaid Keypad GPRS/4G Single Phase Electricity Meter

Advanced Power Management & Remote Monitoring

The STE18-G is engineered for sophisticated power management with seamless remote monitoring capabilities. It integrates GPRS/4G communication to enable real-time electricity data access via web portals, vending systems, handheld units (HHUs), or API-integrated third-party platforms.

This multi-channel connectivity supports comprehensive consumption analytics, usage trend tracking, and instant anomaly alerts for proactive energy optimization.

Modular Design & Infrastructure Flexibility

Featuring a modular plug-and-play design, this meter accommodates diverse smart metering requirements while maintaining STS compliance for data collection and network communications. Utilities can deploy cost-effective solutions across 4G LTE networks based on existing infrastructure.

The component-replaceable architecture minimizes lifecycle costs by enabling module-only upgrades without compromising system performance.

Comprehensive Application Scope

This versatile smart meter serves multiple applications across various sectors:

Residential Communities: Enables landlords to remotely monitor tenant electricity usage for precise billing
Commercial Enterprises: Ideal for supermarkets and offices needing to track energy consumption trends for cost optimization
Rural Electrification: Adapts to remote areas via RF communication for reliable metering in regions with limited network coverage
Municipal Utilities: Supports city-wide smart grid deployments for real-time data collection
Industrial Sub-metering: Monitors department-level energy use in factories and workshops

StronPay Vending System Features

The StronPay vending system offers comprehensive management capabilities for various meter types including electric, water, and gas meters.

Secure Database Management: Microsoft SQL Server backend ensures robust data security
Operational Security: Account permission management guarantees secure system operations
API Integration: Supporting APIs facilitate function expansion and meet personalized needs across different business scenarios
