Name: Prepaid Din-Rail Single Phase Electricity Meter with CIU For Counting The Electricity Consumption
Brand: Hunan Stron Smart Co., Ltd
SKU: STE18-D
Price: 22.00 USD
Availability: InStock

Home > products > Smart Prepaid Electricity Meter >

Prepaid Din-Rail Single Phase Electricity Meter with CIU For Counting The Electricity Consumption

Place of Origin:

China

Brand Name:

STRON

Certification:

ISO 9001 ; ISO 14001, STS Certificated

Model Number:

STE18-D

Request A Quote

Prepaid Din-Rail Single Phase Electricity Meter with CIU For Counting The Electricity Consumption

Product Details

Measurement Unit:

1000imp/kWh

Application:

Counting The Electricity Consumption

Type:

Electricity Meter

Display:

Digital

Power Source:

Electricity

Rf Sensitivity:

-121dBm @2kbps

Communication Technology:

RF/PLC Module

Basic Current:

Operating Temperature:

-25℃-70℃

Storage Temperature:

-40℃-85℃

Keypad:

Support

Maximum Current:

100 Amps

Network Compatibility:

2G And 4G

Payment Method:

Prepaid

Package Dimension:

25.08×20.19×1.62mm

Phasen Number:

Single Phase

Payment & Shipping Terms

Minimum Order Quantity

Price

USD18-26 PC

Delivery Time

5-15DAYS

Payment Terms

T/T

Supply Ability

100PC < 15DAYS

IP54 Waterproof Electrical Counter Meter The Most Accurate Tool for Counting The Electricity Consumption

Get Best Price

Smart Prepaid Electricity Meter Anti-Tamper Protection and Communication with AMI System through Data Concentrator

Get Best Price

STS Standard AMI Smart Meter with Alipay Payment Options Integration Solutions

Get Best Price

2G And 4G Network Compatible Smart Prepaid Electricity Meter The Ultimate Solution for Counting Electricity Consumption

Get Best Price

86-0731-22421066

Contact Now

Product Description

Prepaid Din-Rail Single Phase Electricity Meter with CIU For Counting The Electricity Consumption 0

STD18-B is an STS standard compliant prepaid electricity meter, supports Din Rail mounting and pole mounting, consists of a small-sized meter and customer interface unit (CIU). It can be top up with Stronpay vending software with 20 digits token and communicate with CIU and AMI system.

The CIU is installed inside of user’s house when the meter is kept away from their reach in locked boxes or poles, they can use the CIU to check the data like Credit Remain, Total Purchased and Total Credit by inputting the short code.

Meter Dimension

Prepaid Din-Rail Single Phase Electricity Meter with CIU For Counting The Electricity Consumption 1

Basic Features

✽ STS standard and protocol.

✽ Meter recharged by inputting 20 digits TOKEN.

✽ Ingress protection IP54 waterproof.

✽ Anti-Tamper magnetic field protection.

✽ Real-time clock and low credit alarm.

✽ Event log and data can be stored for 10 years.

✽ Pay by mobile payment M-PESA, Alipay, MTN, Airtel, etc.

✽ The meter could communicate with AMI system through data concentrator.
