Name: High Capacity Wireless Smart RF Laura Prepaid Water Meter Factory Sale IP68 With Split Keypad High Capacity Battery OEM
Brand: Hunan Stron Smart Co., Ltd
SKU: STW36-Q
Price: 45 USD
Availability: InStock

Home > products > Prepaid Water Meter >

High Capacity Wireless Smart RF Laura Prepaid Water Meter Factory Sale IP68 With Split Keypad High Capacity Battery OEM

Place of Origin:

China

Brand Name:

stron

Certification:

STS

Model Number:

STW36-Q

Request A Quote

High Capacity Wireless Smart RF Laura Prepaid Water Meter Factory Sale IP68 With Split Keypad High Capacity Battery OEM

Product Details

Communication Protocol:

RS485

Measurement Unit:

Cubic Meters

Measurement Method:

Volumetric

Ip Rating:

IP68 Waterproof

Electroic Part Case:

Plastic

Working Temperature:

0-40℃

Power Supply:

AC/DC

Mobile Payment:

M-PESA,MTN,Airtel

Rated Power:

10W

Class:

Maximum Pressure Loss:

0.6 Bar

Waterproof:

IP65

Switch Type:

Body Sensitive

Maximum Working Pressure:

16 Bar

Battery Type:

Lithium Battery

Function:

Overdraft Collection

Output Voltage:

110V/120V/220V230V/240V

Material:

Brass

Module:

LORA-RF

Payment Method:

Prepaid

Type:

Multijet

Amr:

Available

Customization:

ODM&OEM

Temperature:

<50℃

Meter Type:

Multi-Jet

Cusotomer Interface:

Yes

Payment & Shipping Terms

Minimum Order Quantity

Price

US$45

Packaging Details

standard

Delivery Time

20days

Payment Terms

T/T

Supply Ability

111110

Contact Now

Product Description

Product Description:

The water meter is an STS standard, token-type prepaid water meter. It has the high quality of IP68 waterproof, allowing operation in harsh environments. The multi-jet structure allows the instrument to operate normally in muddy water and never get stuck. It has a lower pressure loss (<0.06Mpa) and the accuracy is always better after 10 years. There are a variety of types to choose from for different needs.

Prepaid keypad type plastic water meter

Prepaid keypad type brass water meter

Prepaid Split Keypad Brass Water Meter + CIU

Prepaid keypad type brass water meter + CIU

specification

function	Details
advance	STS standard, recharge by entering a 20-bit token
Low credit alerts	You can set the alert value by entering the appropriate token
Prepaid and postpaid switches	Meters can be switched to either prepaid or postpaid
Check valves	Internal check valve to prevent backflow
Tamper-proof	When a magnetic field and lid opening event are detected, the gauge will automatically close the valve
Tiered tariffs	Tiered tariffs can be set by entering the corresponding tokens
Overdraft collection	Non-revenue gas (overdraft) can be collected on a daily basis or on a monthly basis
communicate	The meter can be used with the AMI system via LORA RF or Bluetooth 4.0 upon request
Information inquiry	Consumers can check data such as credit remaining, total purchases, and total credit by entering a short code

Strong point

不同尺寸的计量参数

尺寸		DN15mm 1/2"	DN20mm毫米3/4"	DN25mm毫米1英寸
过载流量Q4		3.13	5	7.875
永久l流量Q3		2.5	4	6.3
过渡流量Q2		0.04	0.064	0.1
最小流量Q1		0.025	0.04	0.063
比率 “R” Q3/Q1		100	100	100
最大工作压力		16巴	16巴	16巴
最大压力损失		0.6巴	0.6巴	0.6巴
最大读数		99999	99999	99999
最高温度		50℃	50℃	50℃
错误	Q1 ≦Q≦ Q2	5%	5%	5%
错误	Q2 ≦Q≦ Q4	2%	2%	2%

仪表尺寸

自动售货流程

自动售货软件的操作

登录售货系统
仪表号登记
客户信息登记
价格设定
开户
自动售货/加满米
获取令牌
用键盘输入令牌到仪表
成功充电

备选方案1: 在当地销售点售货

选项2: 使用第三部分应用程序/移动支付/计费系统使用API自动售货

API:应用程序接口,这是连接第三方应用程序和我们的Stronpay自动售货软件的协议.

公司简介

Stro has maintained long-term cooperation with partners from over 60 countries and regions including South Africa, Nigeria, Tanzania, Kenya, Indonesia, Myanmar, Cameroon, etc.
