Name: STE18-A SMART PREPAID KEYPAD ELECTRICITY METER | SINGLE PHASE DIN-RAIL | 60A MAX CURRENT
Brand: Hunan Stron Smart Co., Ltd
SKU: STE18/STE38
Price: 463.90 USD
Availability: InStock

Home > Products > Smart Prepaid Electricity Meter >

STE18-A SMART PREPAID KEYPAD ELECTRICITY METER | SINGLE PHASE DIN-RAIL | 60A MAX CURRENT

STE18-A Electric Meter

Single Phase DIN-RAIL Electric Meter

PREPAID KEYPAD Electric Meter

Place of Origin:

China

Brand Name:

stron

Certification:

STS

Model Number:

STE18/STE38

Request A Quote

Product Details

Mode:

Prepaid Token Type

Terminal Cover:

Transparent

Phase Number:

Single Phase

Basic Current:

Operation:

Keypad

Color:

White

Charge Mode:

Prepaid

Nominal Frequency:

50-60HZ

Ciu Material:

Plastic

Ingressprotection:

IP54

Phase:

Three Phase

Battery Replacement:

Yes

Feature:

Smart Digital Meter

Keypad:

Yes

Accuracy:

Class 1.0

Product Name:

Prepaid Energy Meter

Rated Voltage:

220-240V/3*220V

Standard:

STS Standard

Display:

LCD

Frequency:

50-60HZ

Warranty:

2 Years

OEM:

Support

Certificate:

ISO9001; ISO14001; STS Standard

Certificate:

ISO9001; ISO14001; STS Standard

Communication:

LORA-RF Supported

Vending Software:

Supported

Recharge Token Length:

20 Digits

Protection Class:

IP54

Battery Life:

8 Years

Current Range:

(5A/80A)/(10A/100A)

Starting Current:

(20mA)/(30mA)

Energy Constant:

(1000imp/kWh)/(400imp/kWh)

Measurement Accuracy:

Class 1.0

Mobile Payment Support:

M-PESA, Alipay, MTN, Airtel, Etc.

Overdraft Collection:

Daily/monthly Optional

Overdraft Collection:

Daily/monthly Optional

Data Storage Duration:

10 Years

Anti-Tampering:

Both With Magnetic Field/cover-opening Detection; STE18-B Cuts Relay, STE38-G Shuts Valve When Triggered

Recharge Method:

(1. Stronpay Software; 2. 3rd-party/mobile Payment)plus 3. AMI System Remote Recharge)

Highlight:

STE18-A Electric Meter

Single Phase DIN-RAIL Electric Meter

PREPAID KEYPAD Electric Meter

Payment & Shipping Terms

Minimum Order Quantity

Price

negotiated

Packaging Details

carton

Delivery Time

5-8 work days

Payment Terms

T/T

Supply Ability

10000

Contact Now

Product Description

Core Features
✅ Prepaid Energy Management

Accepts 20-digit encrypted tokens (TOKEN) for electricity top-up via keypad or paired CIU device.
Auto-alarm when credit is low (red LED flashing) and automatic disconnection at zero balance.
Factory-preloaded with 10kWh credit. Activate by entering anti-tamper token after installation.

✅ Triple-Layer Tamper Protection

Instant Power Cut: Triggers yellow "Warning" light and disconnects supply when cover is opened.
Encrypted Data Security: Complies with IEC62055-31 standard for token fraud prevention.
Reverse Energy Monitoring: Tracks unauthorized backfeeding (Display Code: 2).

✅ Smart Remote Control

433MHz RF Communication: CIU for meter reading (500m range), DCU for batch management (1000m range).
Infrared Port: Enables authorized parameter configuration by utilities.

✅ Real-Time Monitoring

LCD displays 100+ parameters: voltage (Code 3), current (Code 4), real-time power (Code 31), consumption history (Codes 19-30).
LED indicators for pulse (blue), credit status (green/red), and alarms (yellow).

Technical Specifications
⚡ Electrical

Voltage: 230V ±20% (70%-120% Un) | Frequency: 50Hz
Current: 5A (Ib) - 60A (Imax) | Starting Current: 20mA
Accuracy: Class 1.0 per IEC62053-21/23
