Name: Smart Data Concentrator Unit Solar DCU Device with LED Display
Brand: Hunan Stron Smart Co., Ltd
SKU: ST368
Price: 500.00 USD
Availability: InStock

Home > products > Online Vending System >

Smart Data Concentrator Unit Solar DCU Device with LED Display

Solar Smart Data Concentrator Unit

Solar DCU Device With LED Display

Place of Origin:

China

Brand Name:

Stron

Certification:

STS

Model Number:

ST368

Request A Quote

Smart Data Concentrator Unit Solar DCU Device with LED Display

Product Details

Material:

Plastic

Display:

LED

Protection Class:

IP54

Color:

Blue

Weight:

0.8kg

Highlight:

Solar Smart Data Concentrator Unit

Solar DCU Device With LED Display

Payment & Shipping Terms

Minimum Order Quantity

Price

Negotiable

Packaging Details

Carton

Delivery Time

15Days

Payment Terms

L/C, T/T, Western Union, MoneyGram

Supply Ability

1000/month

IP54 Protection Class Hot Food Vending Machine Stronpay-01 for Quick and Easy Food Distribution

Get Best Price

ST-HHU18 Handheld Meter Reading Unit Intelligent Device For Remote Water Reading

Get Best Price

Smart Data Concentrator Unit Solar DCU Device with LED Display

Get Best Price

ST368 Smart DCU Data Concentrator Unit For Energy Meters

Get Best Price

86-0731-22421066

Contact Now

Product Description

Solar Smart Data Concentrator Unit

A solar DCU device is a device designed to provide power to a DCU.Because the use of DCU and the uploading of use information requires DCU to have electricity, and sometimes there is no electricity in the place where the DCU is installed, it will cost a lot of manpower and financial resources to pull the wire to connect the electricity again.So in order to better solve this problem for customers, we specially set up this device.The DCU is powered by a solar-panel generator that will last at least a month once it is fully charged.

ST368 smart data concentrator is dedicated to Smart Metering application and designed as a gateway between metering devices and AMR/AMI system, ST368 creates two ways communication from metering points to AMR/AMRI system, performs task setting, data collection, data transmission and data storage, meter management, GPRS information task execution and RF network management.
ST368 utilize efficiently RS485, RF-LORA media for downlink communication to smart meters and GPRS, 3G, DSL and fiber optic for uplink communication.

Main Features:

a. DLMS/COSEM standard compliant

b. RS485/RF-LORA downlink to smart meters

c. GPRS/3G/DSL uplink communication with a head-end AMR/AMI system

d. Data collection include total consumption/ historical daily & monthly consumption

e, Meter parameter/ status/ Real-time data reading

f. Tamper event record and upload automatically

g. Easy to install due to BS mounting

DCU Parameters:

Working Voltage	160V-300V
Frequency	45-65Hz
Working Temperature	-40℃-+80℃
Humidity Requirement	95%
Display	LED
Built-in Infrared Port	IEC62056-21
Communication Module	GPRS/RF-LORA
RS485 Port	115200bps
Ethernet Port	TCP Protocol
Communication Protocols	DLMS/COSEM
Weight	0.8KG
Protection Class	IP54
Dimension	160x112x58mm
Non-volatile Memory Capacity	128/256MB NANDFLASH

Port display:
