STS 2.5m3/H 1.2L Portable Gas Flow Meter With Aluminum Case

STS 2.5m3/H 1.2L Portable Gas Flow Meter With Aluminum Case

2.5m3/h portable gas flow meter

1.2L portable gas flow meter

2.5m3/h replace gas meter

Place of Origin:

Hunan

Brand Name:

Stron

Certification:

STS

Model Number:

STG16-A

Contact Us
Request A Quote
Product Details
Material:
Aluminum
Size:
Various
Payment:
Prepaid
Type:
Prepaid Gas Meter
Input:
Keypad
Display:
LCD
Communication:
Various
Highlight:

2.5m3/h portable gas flow meter

,

1.2L portable gas flow meter

,

2.5m3/h replace gas meter

Payment & Shipping Terms
Minimum Order Quantity
100
Price
Negotiable
Delivery Time
14 work days
Payment Terms
L/C, D/A, D/P, T/T, Western Union, Western Union
Supply Ability
5000 set per month
Product Description

STG16-A Remote Communication Keypad Prepaid Gas Meter Aluminum Case



The STG16-A is an STS Standard compliant, keypad type, automatically valve controlled prepaid gas meter. It can be top up with Stronpay vending software directly and communicate with AMI system via LORA-RF or NB-IoT module.



The STG16-A can also be integrated with African local mobile money for prepayment, like M-pesa, MTN, Airtel through API(Application Programming Interface), which is the agreement connecting the third party APP and our Stronpay vending software. In this way, users can top up electricity credit by mobile money without leaving the house and could check information by their telephone at hand with internet accessibility.



Compliance with Standard

✽ ISO 9001 ; ISO 14001

✽ STS Certificated



Metrological Parameters of different size



Size G1.6 G2.5 G4
Nominal Flow Rate 1.6 m3/h 2.5 m3/h 4 m3/h
Maximum Flow Rate 2.5 m3/h 4 m3/h 6 m3/h
Minimum Flow Rate 0.016 m3/h 0.025 m3/h 0.04 m3/h
Cyclic Volume 0.7dm3 1.2 dm3 2 dm3
Maximum working pressure 0.7 Bar 0.7 Bar 0.7 Bar
Pressure loss <200 Pa <200 Pa <200 Pa
Maximum reading 99999 99999 99999
Working temperature -20-50℃ -20-50℃ -20-50℃
Storage Temperature -30-60℃ -30-60℃ -30-60℃

Error: Qmin≦Q≦0.1Qmax

0.1Qmax≦Q≦Qmax

±3 ±3 ±3
±1.5 ±1.5 ±1.5



































































Functions

The integrated keypad of gas meter is offered to enter recharge TOKEN and check information by short codes.



Stronpay vending software could be integrated to local Mobile Money Payment Platform like M-PESA, Alipay, MTN, Airtel, etc.



Basic Functions

✽ Meter Recharge: By inputting 20 digits Token.

✽ Low Credit Alarm: Alarm value can be set by inputting corresponding TOKEN.





Communication:

The meter is available with AMI system through LORA-RF or NB-IoT module on request.



Step Tariff:

Meters can be set Step Tariff by inputting corresponding TOKEN. Utilities can set step price on request.



Non- Revenue gas (Overdraft) can be collected day by day or month by month.



Information Inquiry:

Consumer could check the data like Credit Remain, Total Purchased and Total Credit by input the short code.
